DRIVETRAIN-TA65 Star
80
11. Place the remaining grease from the service
kit inside the seal and slide the larger
diameter of the seal with the larger seal
retaining clamp in place over the outside of
CV joint.
Important:
The CV seal must not be dimpled,
stretched or out of shape in any way. If seal is not
shaped correctly equalize pressure.
11. Crimp the seal retaining clamp using pincer
tool and maintain ear gap of 2.6 mm.
