SUSPENSION

2

5.1.2 TIGHTENING TORQUES

SR. NO.

DESCRIPTION

TORQUE VALUE (Kg-m)

FRONT SUSPENSION

1

Front Strut mounting on BIW

2.3

2

Front Strut top mounting

6-7

3

Front strut mounting on Knuckle

8

4

ABS sensor mounting on knuckle

0.8-1.0

5

Driveshaft lock nut

23-26

6

Lower ball joint mounting on knuckle

5.5

7

Lower control arm to BIW mounting (Front & rear pivot)

10

*

Lower control arm front mounting pin & Tie member clamping nut

12

*

Vertical member top & bottom assembly (Partial sub frame)

2.3

8

Antiroll bar mounting on BIW

4.5

*

9

Stab link mounting on strut

5.5

10

Stab link on anti-roll bar

5.5

REAR SUSPENSION

1

Rear Strut mounting on BIW

4.5

2

Rear Strut top mounting

6-7

3

Rear Strut stopper assy.

2

4

Rear Strut bottom mounting

13

5

Torsion beam bracket mounting on body

10

6

Twist beam pivot bush cross bolt

10

*

7

Anchor plate and spindle mounting bolts

4.5

8

Brake drum mounting lock nut

17.5 ± 2
