TIAGO

SUSPENSION

5.1 TECHNICAL SPECIFICATIONS AND TIGHTENING TORQUES

5.1.1 SPECIFICATIONS

(A) Front Suspension

Type:

Independent, lower wishbone, McPherson strut type with anti roll bar at front.

(B) Rear Suspension

Type:

Semi-Independent; closed profile Twist beam with Dual path Strut.

(C) Wheels and Tyres

Tyres:

175/65 R14 82T & 155/80 R13 79T Tubeless tyre

Tyre geometry:

A tyre of size 175/65 R14 82T is made up of following information:

175 - Tyre section width in millimeters

65 - Aspect ratio in % (the height of the side wall divided by the tyre’s width)

R - Tyre’s construction type - in this case it’s a radial type

14 - Rim diameter in inches

82T - Service description (Load Index + Speed Symbol)

Tyre pressure:

Tyre Size

Vehicle Version Wheels

Tyre Pressure

175/65 R14 &

155/80 R13

Petrol

Front

33 psi (2.28 bar)

Rear

30 psi (2.07 bar)

Diesel

Front

33 – 36 psi (2.28 – 2.48 bar)

Rear

30psi (2.07 bar)

NOTE: “Tyre Inflation pressure varies between different variants. Refer Pressure sticker for correct

Inflation pressure".

Wheel Rims:

5J X 14” steel/Alloy rims & 4.5 J X 13” steel rims

(D) Steering geometry (In unladen condition)

Front

Rear

Toe - in

Not applicable

12' ± 15' (Fixed)

Toe - out

0 - 13'

Not applicable

Camber angle

30' ± 30'

-52' ± 60' (Fixed)

Caster angle

1° 45’± 45'

Not applicable

King pin angle

12.8°

Not applicable

Note:

LH / RH Variation in Camber

20'.
