1.05L REVOTORQ ENGINE

95

C. Front Pipe :

Removal :

1. Remove the bolts from Closed Coupled

Catalytic Converter end and Pre-Silencer and

remove the middle pipe.

Fitment :

For fitment follow reverse procedure of

removal.

NOTE



Use new gaskets every time while fitment

and tighten nuts and bolts to specified

torque.

D. Closed Coupled Catalytic Converter :

Removal :

1. Loosen and remove bolts (3 nos) from

exhaust elbow.

2. Loosen and remove bolts (2 nos) from front

pipe.

3. Loosen and remove bolts (2 nos) from CCC

support bracket.

Fitment :

For fitment follow the reverse procedure

of removal.

NOTE



Flushing operation for cleaning the catalytic

converter should be done by directing dry

compressed air draft in the direction of

catalytic converter inlet, after removing it

from the vehicle.
