1.05L REVOTORQ ENGINE
91
16. To remove exhaust front pipe loosen the
clamp near Catcon and clamp near pre
silencer of exhaust pipe
17. Remove battery tray by removing fasteners
(7Nos).
18. Disconnect the gear shift cable and selector
cable from the transaxle.
19. Disconnect the clutch cable connection from
the transaxle.
20. Remove front two tyres.
21. Disconnect the left and right drive shafts from
the vehicle.
22. Use suitable belt/chain to fix a zip crane to the
engine lifting hooks located at front and rear
of the engine.
23. Raise the crane slightly up until very light
pressure is applied to the engine.
24. Remove the nuts on Engine 'B' mounting
bracket.
25. Remove the “A”- mounting bracket nuts (3
nos).
