1.05L REVOTORQ ENGINE
89
3.7 ENGINE ON VEHICLE SERVICE
PROCEDURE:
A. ENGINE REMOVAL :
Description
In many cases, the engine can be
repaired while still in the vehicle. The engine
must be removed in cases where the engine
has been severely damaged beyond repair or
the type of repair necessitates removal. Use
the following procedure as a guide to engine
removal and installation.
Removal
NOTE
Access to an overhead hoist will ease
removal of the engine.
Use a vehicle lifting hoist, if available.
1. Place the vehicle on the two post lift and
engage the parking brake.
2. Open the hood (bonnet) of the vehicle.
3. Disconnect the negative (-) cable and then
the positive (+) cable from the engine.
4. Disconnect and label the Engine wiring
harness connection with ECU.
5. Remove Battery, Battery plate and ECU from
the vehicle.
6. Raise the vehicle off the ground and drain the
engine oil by removing the drain plug into a
suitable container.
7. Drain the engine coolant by removing drain
plug into a suitable container.
