1.2L REVOTRON ENGINE
122
17. Remove the bed plate by removing the
mounting bolts.
18. Remove crankshaft main bearing lower shells
19. Remove crankshaft.
20. Remove thrust washers from 3
rd
bearing from
cylinder block.
21. Remove hex socket counter sunk screw to
separate the crank sensor target wheel from
crankshaft.
