1.2L REVOTRON ENGINE
121
9. Remove connecting rod.
NOTE
Keep each piston and gudgeon pin as a
set, when removed.
10. Using ring expander, remove piston rings
11. Insert flywheel locking pin to lock flywheel.
12. Remove flywheel mounting bolts and then
flywheel locking pin.
13. Remove flywheel by removing six bolts.
14. Remove Crankcase Rear Cover with Rear oil
seal.
15. Remove stiffener plate by removing two
fasteners.
16. Turn the bench at 180˚ to remove crankshaft
from bottom side.
