1.2L REVOTRON ENGINE

113

4. Remove Knock Sensor from Engine Block.

5. Remove Oil Pressure Switch Sensor from

Engine Block.

V. Removal of Accessories.

1. Keep the piston at top dead centre by rotating

crankshaft.

2. Remove dipstick from head cover.

3. Remove Solenoid valve of VCT.

4. Remove ignition coil from head cover by

removing fasteners.
