1.2L REVOTRON ENGINE
108
H. REMOVAL OF ACCESSORIES.
1. Remove the Filter assembly on vehicle.
2. Rotate the tensioner point by using ring
spanner opposite to belt tension to remove the
belt
3. Drain out the coolant.
(For procedure refer
“Coolant
Replacement
”
in
Engine
maintenance section)
4. Remove the coolant inlet hose.
5. Remove the compressor pipes.
6. Remove the compressor upper two fasteners.
7. Remove the compressor lower one fastener.
8. Remove the oil filter by using filter removal
special tool.
