ARIA

ENGINE

31.Remove the touch idler.

32.Place the flange (2)

(Part No 2547 0713 71 03)

on the HP Gear

and tighten the bolts (1) to the

HP pump gear.

33.Now loosen the HP pump gear nut (2) to remove

the HP gear along with the flange and the Lock-

ing pin.

34.Remove auto tensioner bolt and take out the auto

tensioner

35.Loosen and remove the rear timing cover bolts

and takeout the rear timing cover.

36.Remove the intake manifold

(1)

along with its

gasket.

37.Remove all the injectors,

(For procedure refer On

vehicle repairs))
