ARIA

ENGINE

26.Loosen and remove the mounting bolts and take

out exhaust manifold along with its gasket.

27.Loosen and remove mounting bolts and take out

the common rail assembly.

28.Remove the vacuum pump from the cylinder

head.

29.Remove the cylinder head cover assembly.

30.Remove the timing belt

(For removal refer on ve-

hicle repairs.)

NOTE

Use cam shaft locking plate (Part no. 2653 5890

0605) for locking the camshaft gear when the engine

is on stand.
