7. Remove the rear mounting bolts (2), mounted

from below and lower the tank carefully.

INSPECTION

•

Check all hoses and pipes connected to fuel

tank for leaks, loose connections, deterioration

or damage. Replace if necessary.

•

Check fuel pump and fuel level gauge gaskets

for leaks, cracks etc. Replace if necessary.

•

Visually inspect fuel tank for leaks and damage.

Replace if necessary.

•

Check TPV for dust accumulation. Clean if re-

quired.

FITMENT

Follow the reverse order of removal for fitment.

D. TANK UNIT REMOVAL

! CAUTION

•

Unless replacement is necessary, Tank unit, fuel

level sensor should not be removed from the tank

since the rubber parts i.e. gasket, seals etc. may

harden when exposed to air and light.

•

Never apply an excessive force to the tank unit

nipple or lead wire. This may result in bent or

poor contact.

1. Fold the 2

row RH Seat and somersault it to

access the in tank pump cut out.

2. Lift the carpet with foam (1) at the cutout.

3. Loosen and remove the four screws of the cut-

out cover and remove it.
