TRANSAXLE
128
7. Make proper routing of wiring harness clamp
and connect the ‘Transmission Input Speed
Sensor’ female connector carefully.
NOTE
Do not forget to secure the female connector
using the clip provided for the purpose.
8. Connect the ‘Transmission Control Unit’
(TCU) and ‘Electronic Throttle Control (ETC)
wiring harness connectors carefully.
9. Clamp the cylinder head vaccum hose using
plier properly.
10. Tighten clamp of air intake pipe from filter side
as well as from engine side by screw-driver
properly.
11. Tighten all six wing bolts of engine access
cover as per specified torque. (6 Nm).
