BRAKE SYSTEM
541
BRAKES
5. Insert the Primary PistonAssembly (3) into the bore,
with the spring end leading in to the bore. Care must
be taken to guide the seals into the bore, hence
avoiding any damage to the seals.
6. Hold the Tandem Master Cylinder assembly in a
soft jaw vice and depress the push rod assembly.
7. Fit the circlip (8). Ensure the seating of the circlip
squarely into the TMC groove.
With the help of push rod, actuate the master cylinder
pistons couple of times to ensure the quick return of
the piston.
8. Fit the master cylinder boot after liberally lubricating
the inner side of boot with fresh brake fluid.
