NANO

BRAKE SYSTEM

547

BRAKES

3. Lubricate both the Piston assemblies with fresh

brake fluid.

4. Insert Piston assembly, lubricating cylinder bore

with fresh brake fluid.

5. Mount wheel cylinder spring on inserted piston and

insert other piston assembly from opposite

direction.

6. Mount wheel cylinder boot properly on both the

sides.
