ELECTRICAL
49
ELECTRICAL
PARKING/POSITION BULB(
12V , 5W
):
1. Remove the rubber Dust Cap.
2. Remove the bulb along with holder.
3. Pull out the bulb from bulb holder and replace
with new one.
4.Fit the bulb assembly into its position.
5.Fit the rubber dust cap.
TURN INDICATOR BULB (
12V,24W
):
NOTE:
User can not service this bulb (PY24W).It is
possible only at service center after removal of the
Head lamp from vehicle.
1.Cut out Heat staking bosses (
4 Places
).
2.Remove the screws from position (
4 Places
).
3.Remove Plastic Dust Cover.
4.Using two fingers press locking clips as indicated
to release the bulb.
5.Remove the bulb from fuse holder and replace
with new one.
6.Fit the assembly into its proper position.
7.Fit the rubber dust cap.
