ELECTRICAL
32
Single front parking lamp not
working
1. Head Lamp connector
Fix connector properly(10 pole)
loose
2. Grounding point no E6(RH) or
E12(LH) loose
Tighten the grounding properly
3. Bulb fused
Fix the bulb properly. Replace bulb
if blown
4. Parking lamp LH/RH fuse (5A)
Cabin fuse box loose/blown the
circuit and then replace
Fix the fuse properly in the base. i n
If blown, check for short in the fuse
Single rear parking lamp not
working
1. Grounding point no. E1(RH) or
E2(LH) loose
Tighten grounding properly
1. Parking lamp LH/RH fuse(5A)
Cabin fuse box loose /blown
Fix the fuse properly in the base, i n
if blown, check for short in the
circuit and then replace the fuse
2. Bulb fused
Replace bulb if blown
3. Battery supply not reaching lamp
LH/RH fuse input
the discontinuity in the circuit.
Check the continuity from p a r k i n
g battery to the lamps through the
combi-switch, Front W/Hand Floor
W/H connectors and rectify
Both parking lamps not
working at all
1. Combi switch connectors loose
Fix the connectors properly
2. Combi switch faulty
Replace combi –switch
registration plate lamp not
working
1. Bulb fused
Replace bulb
2. Grounding point no. E2 loose
Tighten grounding properly
3. 2 pole lamp connector loose
Fix connector properly
Cabin lamp not working in
‘ON’ position
1. Bulb fused
Fix the bulb properly. Replace bulb
if blown
2. Switch erratic
Replace roof lamp
3. 3 pole Roof lamp switch
connector loose
Tighten the connector
CONNECTION DETAILS
For Circuit refer circuit schematic section.
