STARTER MOTOR SPECIFICATIONS:
OUTPUT
1.4KW MIN
ENGAGING
SYSTEM
PRE-ENGAGED DRIVE
PERFORMANCE
SPECIFICATION
AT +27ºC
CONDITION VOLTAGE(VOLTS) CURRENT(AMP) TORQUE(Nm) SPEED(RPM)
NOLOAD
11.5
70MAX
N/A
5000
LOAD
9.8
250MAX
7MIN
1600MIN
LOCKED
5.5
700MAX
22MIN
N/A
OPERATION OF
SOLENOID
SWITCH
1) PULL IN VOLTAGE 8V WHEN PINION TRAVEL RESTRICTED AT 3MM
2) DROP OFF VOLTAGE 4V MAX
INTERNAL
TRANSMISSION
RATIO
1:6
WEIGHT
3.3Kg
PACKAGING
214×171.5×106.5
SALIENT FEATURS:
Reinforced armature.
Special bearing grease.
Long life characteristics by new brush-slip ring system and reinforced end shields.
Designed for application with High Thermal load.
