ZEST AND BOLT - page 1007

ELECTRICAL
40
12.8.7 HIGH MOUNTED STOP LAMP
REMOVAL AND RIFITMENT OF HIGH
MOUNTED STOP LAMP
REMOVAL
1. Open the tail gate.
2. Remove the spoiler after removing the nut.
3. Remove the high mounted stop lamp cover.
4. Press the clip on the high mounted stop lamp
5. Disconnect the electrical connection and
remove the lamp.
6. Remove the bulb if required, bulb type 5nos.
REFITMENT
1. Reconnect the stop lamp connector.
2. Align & snap refit two fasteners of high
mounted stop lamp.
3. Refit the spoiler.
