ELECTRICAL
30
Both lamps not working
1.Fog lamp fuse (20A) in cabin
F/R box blown
Check for short in the circuit and
then replace the fuse
2.Front fog lamp relay(20A) in
Engine F/R Box faulty
Replace relay
3. Front fog lamp switch faulty
Replace switch
4. No output from BCM
Refer BCM Diagnosis
1. Front fog lamp switch ground
point E0 loose
Tighten grounding properly
2. Bulb loose/fused
Fix bulb properly. Replace if blown
3 REAR FOG LAMP (HIGH END) CONTROLLED BY BCM
CONDITION
POSSIBLE CAUSE
CORRECTION/REFERENCE ITEM
Single lamp not working
1. Grounding point no. E1(RH) or
E2(LH) loose
Tighten grounding properly
2. Bulb loose / fused
Fix bulb properly in holder. Replace
bulb if blown
3. No output from BCM
Refer BCM Diagnosis
Both lamps not working
1. Fog lamp fuse (20A) in F/R box
blown cabin
Check for short in the circuit and
then replace the fuse
2. Rear fog lamp switch faulty
Replace switch
3. No output from BCM
Refer BCM Diagnosis
Rear fog lamp switch on-state
indication not lighting
1. Bulb loose/fused
Fix bulb properly. Replace if blown
2. Rear fog lamp switch ground
point E9 loose
Tighten grounding properly
4
INDICATOR LAMP WARNING LAMP AND OTHER LAMPS
CONDITION
POSSIBLE CAUSE
CORRECTION/REFERENCE ITEM
Front right / left signal lamps
not working
1. Grounding point no. E6(RH) or
E12 (LH) loose
Tighten the grounding properly
2. 8 pole Head Lamp connector at
the lamp loose
Fix the connector properly
3. Bulb fused
Fix the bulb properly. Replace bulb if
blown
