ELECTRICAL
31
Rear right / left turn signal lamps
not working
1. Grounding point no. E1(RH) or
E2 (LH) loose
Tighten grounding properly
2. 8 pole Rear Lamp Connector
loose
Fix the connector properly
3. Bulb fused
Fix the bulb properly. Replace
bulb if blown
Both Turn Indicators not working
1. Flasher fuse (10A) in cabin fuse
box loose/blown(BASE & MID)
Fix fuse properly in the base.
Replace fuse if blown
2. Flasher in cabin fuse box
faulty(BASE & MID)
Replace Flasher
3. No output from BCM (HIGH)
Refer BCM Diagnosis
Side repeater lamps not working
1. Connectors (2 pole) at the
lamps loose
Connect the connectors properly
2. Bulb loose/ blown
Fix the bulb properly. Replace
bulb if blown
3. Grounding point no.
Tighten grounding properly E6
(RH) or E12 (LH) loose
4. No output from BCM (HIGH)
Refer BCM Diagnosis
Indicator lamps not working
when hazard warning switch is
operated
1. 8 pole connector at the front
facia panel switch loose
Fix the connector terminal
properly
2. Hazard warning switch faulty
Replace switch
3. No output from BCM
Refer BCM diagnosis
Reverse lamp not working
1. Grounding point no. E00 loose
Tighten grounding properly
2. Bulb fused
Replace bulb if blown
3. 8 pole tail lamp connector
loose.
Fix the connector properly
Stop(Brake) lamps not working
1. 8 pole tail lamp connector loose Tighten the connector properly
2. Bulbs fused
Fix the bulbs properly. Replace
bulbs if blown
3. Brake lamp switch faulty
Replace switch
Stop(Brake) Lamp and High
Mounted Stop Lamp not working
1. Stop Lamp and High Mounted
Stop lamp 5A Fuse in Cabin Fuse
Box Blown
Replace Fuse
