ELECTRICAL
28
12.8 LIGHTING SYSTEM
12.8.1 BULB SPECIFICATIONS
SR.NO DESCRIPTION
RATING
TYPE
QUANTITY
1
High Beam
12V , 55W
H1
2
2
Low Beam
12V , 55W
H7
2
3
Front Turn Signal
12V , 21W
PY21
2
4
Front Fog Lamp
12V , 19W
H16
2
5
Position Lamp
12V , 5W
W5W
2
6
Stop + Position Lamp
12V , 21/5W
P21/5W
2
7
Rear Turn Signal
12V , 21W
PY21W
2
8
Reverse Lamp
12V , 21W
P21W
2
9
Rear Fog Lamp
12V , 21W
P21W
1
10
Rear Registration Plate LED
12V , 5W
LED
2
11
Side Repeater Lamp
12V , 5W
WY5D
2
12
Roof Lamp
12V , 10W
Festoon Bulb
1
13
Roof Spot Lamp
12V , 5W
W5W
2
14
High Mounted Stop Lamp
-
LED
1
15
Load Area Lamp
12V , 5W
W5W
1
12.8.2 FASTENERS TORQUE VALUE TABLE
SR.NO.
APPLICATION
TORQUE VALUE
1
Head Lamp Mounting (M6 x16)
0.65 Kgfm
2
Front Fog Lamp Mounting ()
0.65 Kgfm
3
Tail lamp – Hatch (M6x16(Hex FL SCR))
0.65 to 0.7 Kgfm
4
High mounted stop lamp
0.6 Kgfm
5
Rear Fog lamp Mounting
(SNAP FIT)
SNAP FIT
7
DRL
-
8
SRL
-SNAP FIT
9
RPL
-SNAP FIT
