12.8.3 GENERAL SYMPTOMS AND DIAGNOSTICS
1. HEAD LAMPS HIGH/LOW BEAM
CONDITION
POSSIBLE CAUSE
CORRECTION/REFERENCE ITEM
Single head lamp (RH or LH)
not working
1. Grounding point no. E6 (RH)
or E12 (LH) loose
Tighten grounding properly
2. Head Lamp 8 pole connector
loose
Fix connector properly
3. High/Low beam
terminal(Pink/Blue wire) has com
off the 8 pin connector
Insert the terminal into the connector
properly
4. HL Low Beam 15A Fuse or HL
High Beam 15A Fuse in Engine
F/R Box blown
Replace the fuse
5. HL Low Beam Relay(20A) or
HL High Beam Relay(20A) in
Engine F/R Box loose
Fix the relay properly
6. High/Low beam filament in the
bulb blown
Replace bulb
Both lamps not working
1. Head lamp ON Relay(20A) in
engine F/R Box loose
Fix the relay properly
2. Connectors at combi-switch
loose
Fix the connectors properly
3. High / Low beam switch in
combi-switch faulty
Replace combi-switch
High beam does not come on
when flash switch is activated
1. Combi Switch connector loose Fix the connector properly
2. Flash switch faulty
Replace combi-switch
2 FRONT FOG LAMP (HIGH END) CONTROLLED BY BCM
CONDITION
POSSIBLE CAUSE
CORRECTION/REFERENCE ITEM
Single LAMP not working
1. Grounding point no. E6 (RH)
or E12 (LH) loose
Tighten grounding properly
2. Bulb fused
Replace bulb
3. No output from BCM
Refer BCM Diagnosis
