Revotron 1.2T
109
13. Remove Crankcase Rear Cover with Rear oil
seal.
14. Remove the main bearing caps, by removing
the mounting bolts.
15. Remove crankshaft main bearing shells and
thrust washers from bearing 4
th
from cylinder
block.
NOTE
•
While removing Main Bearing shell, mark
on its back in case of reuse.
16. Remove the crankshaft.
17. Remove Piston cooling Nozzles with Gasket
from the cylinder block.
