Revotron 1.2T
101
4. Remove Knock Sensor from Engine Block.
5. Remove Oil Pressure Switch Sensor from
Engine Block.
v. Removal of Timing Belt
1. Remove the Cylinder Head Cover from the
engine & carefully placed the rubber gasket
apart.
2. Remove Timing Cover Front Upper.
3. Remove the “A-Mount Bracket” from the font
cover assembly.
