KRYOTEC ENGINE
90
46. Install the battery (Refer to 08 -
Electrical/Battery System/BATTERY/Removal and
Installation).
47. Evacuate and charge the refrigerant system
(Refer
to
24
-
Heating
and
Air
Conditioning/Plumbing - Standard
Procedure).
48. Fill the cooling system (Refer to 07 - Cooling -
Standard Procedure).
49. Fill the transmission (Refer to 21 -
Transmission
and
Transfer
Case/Manual/FLUID/Standard Procedure).
50. Bleed the clutch hydraulic circuit (Refer to 06 -
Clutch/Standard Procedure).
51. Install the front fascia (Refer to 13 - Frame and
Bumpers/Bumpers/FASCIA, Front/Removal and
Installation).
52. Install the front wheel splash shields (Refer to
23 - Body/Exterior/SHIELD, Splash/Removal and
Installation).
53. Install the front belly pan (Refer to 13 - Frame
and Bumpers/Under Body Protection/BELLY
PAN/Removal and
Installation).
54. Install the front wheels (Refer to 22 - Tires and
Wheels/Removal and Installation).
55. Remove the vehicle from the lift.
C. CYLINDER HEAD
REMOVAL
1. Remove the battery tray (Refer to 08 -
Electrical/Battery System/TRAY, Battery/Removal
and Installation).
2. Remove the engine cover (Refer to 09 -
Engine/COVER, Engine/Removal and Installation).
3. Remove the EGR cooler (Refer to 25 -
Emissions Control/Exhaust Gas Recirculation,
Diesel/COOLER, Exhaust Gas Recirculation
(EGR)/Removal and Installation).
4. Remove the cylinder head cover (Refer to 09 -
Engine/Cylinder
Head/COVER(S),
Cylinder
Head/Removal and Installation).
5. Disconnect the glow plugs wire harness
connectors 1).
6. Disconnect the boost pressure sensor wire
harness connector (1).
