BODY
28
5. Slowly pull out the door and pull out the wiring
harness carefully which was disconnected
earlier.
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE:
a) For fitment bolts (Self aligning bolt) shown as
1
st
to be fasten first & then bolt shown as
2
nd
2.17 REAR DOOR TRIM
REMOVAL
1. Open the Door.
2. Remove window-winding switch from door
pull outer.
3. Disconnect the window winding connection
and remove the switch.
4. Remove the mounting screw and pull out the
arm rest.
5. Loosen and remove the mounting screw of
inner handle.
