505 / 1119
TRANSAXLE - TA65 Star
48
4. Pull out the top cover with bush from the
selector shaft.
5. Remove the dust cover with Oil Seal.
23. ASSEMBLY TOP COVER:
1. Place the selector shifter shaft along with dust
cover in the top cover.
2. Put the lower diameter spring (1st/2nd
Selection) after placing spacer over the shaft
as shown and place the larger diameter spring
(5th / reverse Selection )
