TRANSAXLE - TA65 Star
51
25. REMOVAL OF GEAR SHIFTER AND
SELECTOR CABLE:
1. Ensure the gear lever in neutral condition.
2. Remove Lever knob, washer, cap screw and
base plate. (Refer body section).
3. Remove the floor console Assembly. (Refer
body section).
4. Pry out both the cable lock plates and remove
the cables from assembly gear shift housing.
5. Disconnect Gear selector cable from gear
shifter Linkage housing.
6. Rotate gear shifter housing, Remove lock pin
& pry out the shifter cable.
7. Pry out the shifter selector cable ends from the
transaxle housing.
8. Pull out the plunger from transaxle cable and
remove it from the transaxle cable anchoring
bracket.
9. Loosen the cable grommet nut mounting from
firewall to remove the assembly.
