1.5L REVOTORQ ENGINE
109
B. GLOW PLUG
REMOVAL
1. Remove the engine cover.
2. Disconnect the electrical connection of the
glow plugs.
3. Loosen and remove the 4 glow plugs.
FITMENT
For fitment follow removal procedure in reverse.
C. FUEL FILLER NECK ASSEMBLY AND
BREATHER HOSE
Refer Body section for removal and refitment
procedures.
D. FUEL TANK
REMOVAL
1. Place the vehicle on a 2 poster lift.
2. Disconnect the fuel filler hose and the breather
hose.
3. Support the fuel tank from below.
4. Remove the parking brake cable routed on the
tank’s parking brake clamp.
5. Remove the four mounting bolts from fuel tank
mounting straps and lower fuel tank gradually
until electrical connector of Fuel Delivery
Module unit can be reached to disconnect.
6. Disconnect the electrical connections of the
Fuel Delivery Module and its fuel lines.
7. Remove fuel tank from vehicle.
