1.5L REVOTORQ ENGINE
107
A. FUEL RAIL
REMOVAL
1. Remove the engine cover.
2. Disconnect the electrical connection of the
fuel rail sensor.
3. Disconnect the electrical connection of the
glow plugs.
4. Disconnect the electrical connection of the
injector and the cam angle sensor.
5. Remove the back leak hose connected of the
fuel injectors.
6. Remove the mounting bolts of the harness
support bracket on the intake manifold and
take out the harness.
7. Remove the mounting bolts of the support
brackets mounted on the intake manifold.
