6.2.

If Both E-Keys are lost

Applicability: when both original E keys are lost & to be prepared new

Dealer,

Gets Key-Tag no. from customer

Attends the vehicle (where ever it is)

Notes down Information on Immobilizer label (Serial no., H/w & s/w version).

Send the lockset number engraved on lockset to supplier

SPD orders E-keys (2 nos.)

Pre-requisites :

Original Immobilizer with new E-keys (2nos.), reconfirm part received is same as

sent back.

Diagnostic tester for immobilizer

Checking of New E-key:

Insert New

E-key

in the SCL (

Steering Column Lock

) and turn on to IGN-ON

position.

The Status lamp should be blinking at ignition OFF

Operation Details with Diagnostics Tester:

1.Connect Diagnostic Tester to the diagnostics connector.

2.Turn E-key to IGN-ON position.

3.Diagnostics tester:

Issue “Start Communication” command

Clear Immobilizer DTC.

Start -

“Erase Key” command

4.After immobilizer receives “Erase E-Key” command from the diagnostic tester, all other

E-keys (which are lost) are removed from ICU’s memory, so other E-keys become

redundant.

5.Then give “Additional E-Key Learning” routine. The immobilizer status lamp starts

blinking stating that immobilizer has learnt the E-key in the SCl and ready to learn

another E-Key.

6.Remove the E-key from the SCL and insert the new E-Key into the SCL and trun the IGN

ON within 50 seconds.

7.When the ICU is learning the key, the Status lamp turns

. Once learning of that key

is successful, the Status lamp starts

blinking

indicating that ICU is ready to learn

another E key.

8.To

learn more keys, go to step 6.

9.To

stop the learning process, do any one of the following

Leave the learned key in the SCL for more than 50 seconds – after which Immo

Status lamp will be continuously ON, indicating learning operation is complete.

Remove the key from the Ignition lock and wait for more than 50 seconds - After 50

seconds the Immo Status lamp will be continuously ON, indicating learning

operation is complete.
