SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 543 of 549
Pin
No.
Pin Name Description
1 CAN_H CAN High
2 CAN_L CAN Low
7 A_GND Common Switch GND
12 V bat Supply Voltage Battery
23 GND Power GND
Please refer Airbag ECU Pin Assignment on or more details.
Inspection Method:-N.A
CHAMBER A
