SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 545 of 549
Sr no
(DTC
ID)
Display DTC
Code
DTC Description
Display
Status
(Mask status)
23
B100E-86
Frontal Impact Driver sensor signal invalid
N
24
B100E-11
Frontal Impact Driver sensor circuit short to ground
N
25
B100E-12
Frontal Impact Driver sensor circuit short to battery
N
26
B100E-64
Frontal Impact Driver sensor Signal Plausibility failure
N
27
B100E-96
Frontal Impact Driver sensor component internal failure
N
28
B100F-2B
Frontal Impact Passenger sensor signal cross coupled
N
29
B100F-4A
Frontal Impact Passenger sensor Incorrect component
installed
N
30
B100F-86
Frontal Impact Passenger sensor signal invalid
N
31
B100F-11
Frontal Impact Passenger sensor circuit short to ground
N
32
B100F-12
Frontal Impact Passenger sensor circuit short to battery
N
33
B100F-64
Frontal Impact Passenger sensor Signal Plausibility failure
N
34
B100F-96
Frontal Impact Passenger sensor component internal failure
N
35
U1006-43
Control Module Internal special memory failure
N
36
U1006-49
Control Module Internal Internal electronic failure
N
37
U3006-16
Control Module Input Power "A" circuit voltage below
threshold
N
38
U3006-17
Control Module Input Power "A" circuit voltage above
threshold
N
39
B1011-00
Front Deployment Crash no sub type information
N
40
B1012-00
Belt Pretensioner Deployment Crash no sub type
information
N
41
B1014-00
Crash Recorder Locked no sub type information
N
42
B1016-00
SRS Lamp Status no sub type information
N
43
U0028-13
Vehicle Communication Bus A – circuit open
N
44
U0028-88
Vehicle Communication Bus A – Bus Off
N
45
U0155-08
Lost Communication with Instrument Panel Cluster (IPC)
Control Module Bus Signal / Message Failures
N
46
U0140-08
Lost Communication with Body Control Module Bus Signal /
Message Failures
N
47
U0423-81
Invalid Data received from Instrument Panel Cluster Module-
Invalid serial data received
N
48
U0422-81
Invalid Data Received from Body Control Module - Invalid
serial data received
Y
49
B00D5-55
Restraint System Passenger Disable Indicator not
configured
N
50
B00D5-14
Restraint System Passenger Disable Indicator circuit short
to ground or open
N
51
B00D5-12
Restraint System Passenger Disable Indicator circuit short
to battery
N
52
B100B-55
Passenger Deactivation switch (PADS) not configured
N
53
B100B-2B
Passenger Deactivation switch (PADS) signal cross coupled
N
54
B100B-12
Passenger Deactivation switch (PADS) circuit short to
N
