SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 547 of 549
Sr no
(DTC
ID)
Display DTC
Code
DTC Description
Display
Status
(Mask status)
84
B100C-4A
Driver Side Peripheral Sensor Incorrect Component
Installed
N
85
B100C-86
Driver Side Peripheral Sensor signal Invalid
N
86
B100C-11
Driver Side Peripheral Sensor circuit to ground
N
87
B100C-12
Driver Side Peripheral Sensor circuit short to battery
N
88
B100C-64
Driver Side Peripheral Sensor signal plausibility failure
N
89
B100C-96
Driver Side Peripheral Sensor component internal failure
N
90
B100C-55
Driver Side Peripheral Sensor Deployment Control not
configured
N
91
B100D-4A
Passenger Side Peripheral Sensor incorrect component
install
N
92
B100D-86
Passenger Side Peripheral Sensor signal invalid
N
93
B100D-11
Passenger Side Peripheral Sensor circuit short to ground
N
94
B100D-12
Passenger Side Peripheral Sensor circuit short to battery
N
95
B100D-64
Passenger Side Peripheral Sensor signal plausibility failure
N
96
B100D-96
Passenger Side Peripheral Sensor component internal
failure
N
97
B100D-55
Passenger Side Peripheral Sensor Deployment Control not
configured
N
98
B0021-55
Left Curtain Deployment Control not configured
N
99
B0021-11
Left Curtain Deployment Control circuit short to ground
N
100
B0021-2B
Left Curtain Deployment Control signal cross coupled
N
101
B0021-1A
Left Curtain Deployment Control circuit resistance below
threshold
N
102
B0021-1B
Left Curtain Deployment Control circuit resistance above
threshold
N
103
B0021-12
Left Curtain Deployment Control circuit short to battery
N
104
B0029-55
Right Curtain Deployment Control not configured
N
105
B0029-11
Right Curtain Deployment Control circuit short to ground
N
106
B0029-2B
Right Curtain Deployment Control signal cross coupled
N
107
B0029-1A
Right Curtain Deployment Control circuit resistance below
threshold
N
108
B0029-1B
Right Curtain Deployment Control circuit resistance above
threshold
N
109
B0029-12
Right Curtain Deployment Control circuit short to battery
N
110
B0075-1A
Second Row Right Seatbelt Pre tensioner Deployment
Control circuit resistance below threshold
N
111
B0075-1B
Second Row Right Seatbelt Pre tensioner Deployment
Control signal cross coupled
N
112
B0075-11
Second Row Right Seatbelt Pre tensioner Deployment
Control circuit short to ground
N
113
B0075-12
Second Row Right Seatbelt Pre tensioner Deployment
Control circuit short to battery
N
114
B0075-55
Second Row Right Seatbelt Pre tensioner Deployment
Control not configured
N
115
B100D-2B
Passenger Side Peripheral Sensor cross coupled
N
116
B1033-55
Invalid CAN Node Selection not configured
N
