SRS / Airbag
ECU – DTC Troubleshooting Guide
Version: 14.0
Date: 14-February-2017
Prepared by:Airbag COC Review &
Approved by:Sanjeev VM
Page: 546 of 549
Sr no
(DTC
ID)
Display DTC
Code
DTC Description
Display
Status
(Mask status)
battery
55
B100B-1B
Passenger Deactivation switch (PADS) circuit resistance
above threshold
N
56
B100B-1A
Passenger Deactivation switch (PADS) circuit resistance
below threshold
N
57
B100B-1F
Passenger Deactivation switch (PADS) circuit intermittent
N
58
B1010-55
Crash output HW not configured
N
59
B1010-14
Crash output HW circuit short to ground or open
N
60
B0020-1A
Left Side Airbag Deployment Control circuit resistance
below threshold
N
61
B0020-1B
Left Side Airbag Deployment Control circuit resistance
above threshold
N
62
B0020-11
Left Side Airbag Deployment Control circuit short to ground
N
63
B0020-2B
Left Side Airbag Deployment Control signal cross coupled
N
64
B0020-12
Left Side Airbag Deployment Control circuit short to battery
N
65
B0020-55
Left Side Airbag Deployment Control not configured
N
66
B0028-1A
Right Side Airbag Deployment Control circuit resistance
below thresh
N
67
B0028-1B
Right Side Airbag Deployment Control circuit resistance
above threshold
N
68
B0028-11
Right Side Airbag Deployment Control circuit short to
ground
N
69
B0028-2B
Right Side Airbag Deployment Control signal cross coupled
N
70
B0028-12
Right Side Airbag Deployment Control circuit short to battery
N
71
B0028-55
Right Side Airbag Deployment Control not configured
N
72
B0073-55
Second Row Left Seatbelt Pre tensioner Deployment not
configured
N
73
B0073-1A
Second Row Left Seatbelt Pre tensioner Deployment
Control circuit resistance below threshold
N
74
B0073-1B
Second Row Left Seatbelt Pre tensioner Deployment
Control circuit resistance above threshold
N
75
B0073-11
Second Row Left Seatbelt Pre tensioner Deployment
Control circuit short to Ground
N
76
B0073-2B
Second Row Left Seatbelt Pre tensioner Deployment
Control signal cross Coupled
N
77
B0073-12
Second Row Left Seatbelt Pre tensioner Deployment
Control circuit short to battery
N
78
B1010-12
Crash output HW circuit short to battery
N
79
B1013-00
Side Deployment Crash no subtype information
N
80
U0422-81
Invalid Data received from Body control Module-Invalid
Serial Data received
N
81
U0100-08
Lost Communication with ECM/PCM “A”-Bus Signal/
Message Failures
N
82
U0401-81
Invalid Data Received from ECM/PCM "A"-Invalid serial data
received
N
83
B100C-2B
Driver Side Peripheral Sensor Signal Cross Coupled
N
