Trouble Shooting:-
Is DTC
B1F36-23 is
Present?
Check for Control panel OFF
Request Button functionality.
Check the Control panel shall
be OFF by pressing OFF button
Is OFF button
stucked?
Check and lubricate switch if still the OFF
button is stucked then replace control
panel.
Clear the DTC from the ECU
memory.
Turn Ignition OFF & ON.
Check the control panel shall be
OFF by pressing OFF button
Stop
Stop
YES
NO
YES
NO
Turn ON Ignition.
Connect the TML Diagnostic Tool.
Check the status of DTC’s (Memorized/Current)
Record the DTC & Clear DTC’s
Turn Ignition OFF & ON
Verify If DTC B1F36– 23 is present
