ESP DTC Troubleshooting Data
Version: 1.0
Date: 23-Oct-15
Author: ERC, Chassis E&E CoC
Page: 218 of 224
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
EMS ECU Schematic:
Pin Details:
Pin Description
Pin No.
Battery
201, 205 and 203
GND
202, 204 and 206
IGN
219
CAN_H
248
CAN_L
247
