Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 652 of 855
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Start
Connect the Diagnostic Tool and check for DTCs
Is DTC B2267 – 09
present?
STOP
NO
Check DTC present is Current or history
YES
History?
1. Clear the DTC from memory.
2. Turn the IGN to OFF.
3. Start the IGN.
4. Check for DTCs.
YES
Is DTC B2267 – 09
present?
NO
NO
YES
Disconnect vehicle battery connection.
(Please follow the safety guidelines)
B2267– 09 : Emergency HW Path Failure – Component Failure
BCM ECU faulty
Replace BCM ECU
