Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 648 of 855
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
B2269– 15 : Rear Left Turn Indicator LEDs – circuit short to battery or open
Start
Connect the Diagnostic Tool and check for DTCs
Is DTC B2269 – 15
present?
STOP
NO
Check DTC present is Current or history
YES
History?
1. Clear the DTC from memory.
2. Turn the IGN to OFF.
3. Start the IGN.
4. Check for DTC.
YES
Is DTC B2269 – 15
present?
C
Check BCM and Rear left turn indicator LED
connectors for terminal backout
NO
C
Are connectors loose?
Reconnect connectors firmly
B
1. Remove BCM side wiring harness connector.
2. Perform visual check of connectors for pins bend or
damaged etc.
A
NO
YES
YES
NO
Disconnect vehicle battery connection.
(Please follow the safety guidelines)
