TRANSMISSION
38
22. Remove the transfer box connector.
23. Loosen the 6 nuts and remove the transfer
box.
BE CAREFUL
:
The transfer box weighs approx. 30 kg.
24. Disconnect the vehicle connector. See
Mechatronic Removing Procedure.
25. Loosen the oil cooler line screw by using a
H12 wrench, and remove the oil cooler line.
