50

7. Remove the lower mounting bolt of bottom

anchorage and take out the seat belt

assembly.

FITMENT:

For fitment follow reverse procedure of removal.

IV.

SECOND ROW SEAT BELT:

REMOVAL:

1. Loosen and remove the lower mounting bolt of

the seat belt.

2. Remove the “C” pillar trim.

3. Remove the rear quarter trim.

(For procedure

refer rear quarter removal process,)

4. Remove the AC duct to have access to the

mounting bolt.

5. Loosen and remove the upper mounting bolts

of seat belt below C pillar.
