4. Remove load floor.
5. Loosen and remove the mounting bolts from
the rear side of the seat and remove it from the
vehicle.
ASSEMBLY:
For assembly follow the reverse procedure of
removal.
III.
FRONT ROW SEAT BELT:
REMOVAL:
1. Fold the front seat to have easy access for the
belt removal.
2. Remove the lower mounting of seat belt.
3. Remove “B” pillar trim.
(For procedure refer “B”
pillar trim removal process.)
4. Remove the upper mounting bolt and the pan
head screw.
5. Remove the B pillar garnish.
6. Remove the B pillar garnish.
