1616 / 1906
ELECTRICAL
314
8.17.3 TWEETER:
Tweeter is a loudspeaker designed to produce high
frequencies.
1. XT VARIANT
2. Other VARIANTS
LOCATION:
It is fitted on A-pillar panel.
REMOVAL:
1. Remove the A-pillar trim. (
Refer body section
)
2. Disconnect the electrical connection of tweeter.
3. Loosen and remove the two mounting screws of
tweeter.
4. Take out the tweeter by removing its connector
from its parking position.
