ELECTRICALS
15H. RHEOSTAT
Fig. 37
Function
It generates a variable voltage to control the
brightness of instrument cluster lights.
Location
LH side of instrument cluster on the dashboard.
15I. ROOF LAMP
Fig. 38
Function
They illuminate the passenger compartment and
luggage compartment .
Location
They are located on the roof at B pillar and in
luggage compartment.
EARTH
SUPPLY
Br-L DOOR EARTH
Fig. 37
Fig. 38
O - OFF
I - DOOR CONTROL
II - ON
W Gr
Br
PARK SUPPLY +VE
DIMMER
OUTPUT
EARTH -VE
Br
R-
W
