SAFARI

ELECTRICALS

16. ANTITHEFT DEVICE :

Immobiliser (If fitted)

Immobiliser (Anti-theft security system) if fitted : This

system disables the starter motor circuit, ignition

supply and fuel cut-off solenoid supply and fuel cut-

off solenoid supply. The vehicle can be started only if

the key fitted with corresponding transponder is

inserted in the ignition switch.

A. Programming the keys of the vehicle

equipped with transponder :

1. Insert a key with transponder in the ignition switch

and turn to “ON” (+15) and then to OFF.

2. Take away the key from the ignition switch : the

LED starts flashing fast for 30 seconds, during

this time move the transponder master card close

to the ignition switch Fig. 42 (where) the antenna

is located) and wait until the LED goes off.

3. Move the transponder master card away: the LED

starts flashing very fast for 30 seconds, during

this time the system is set for the 1st transponder

self-learning.

4. Insert the 1st transponder key in the ignition

switch : LED will go off; the 1st key is

programmed.

5. Take away the programmed key from the ignition

switch : the LED starts again to flash very fast for

another 30 seconds, during this time.

6. Insert the 2nd transponder key in the ignition

switch : the LED will go off; the 2nd key is

programmed. Take away the key from the ignition

switch.

7. If the vehicle is equipped with only 2 keys, wait

for 30 seconds, : the LED will go off and then

start to flash slowly. The programming cycle is

finished.

8. If the vehicle is equipped with a 3rd transponder

key, don’t wait for 30 seconds, and insert the 3rd

key in the ignition switch : the LED will go off and

start to flash slowly. Take away the 3rd key from

the ignition switch. The programming cycle is

finished.

Fig. 42

- The operations have to be made in the right time;

otherwise the function will finish.

- In case of mistakes, repeat the programming

procedure from the very beginning.

B. Disabling/Enabling the immobilizer in the

event of breaking or loosing the keys with

transponder :

1. Insert a key without transponder in the ignition

switch and turn to “ON” : the LED goes off. Move

the transponder master card close to the ignition

switch: the LED remains switched off. The

immobilizer is disabled. Move the transponder

master card away : the vehicle normally runs.

2. The immobilizer is automatically ENABLE after

30 seconds turning the key to OFF.

3. To switch on the vehicle again, using the key

without transponder, proceed as indicated at point

B1.
