15. SWITCHES, INTERIOR LAMPS &
OTHER COMPONENTS
15A. GLOVE BOX SWITCH / LAMP
Fig. 28
Function
It illuminates the box when the box is opened.
Location
Inside the glove box on the dash board, in front
of co-driver.
15B. FRONT INTERIOR LAMP
Fig. 29
Function
It is a combination of one roof lamp and two spot
lamps. Spot-lamps facilitates the driver and co-
driver in map-reading etc.
Location
It is located on the roof behind internal rear view
mirror.
Br-L R-W Br
EARTH
SUPPLY
DOOR
EARTH
Fig. 28
Fig. 29
O - OFF
I - DOOR CONTROL
II - ON
Push
Buttons
II IO
