ELECTRICALS
15G. DOOR MIRROR SWITCH
(Optional)
Fig. 36
Function
It facilitates sideways as well as up & down
movement of mirror on both sides
Location
It is located on the switch pack of driver side
door.
Fig. 36
DOWN
UP
COLOUR CODE
Br/B
G/B
Br/Y
G/Y
Br
B/W B
SIDE MOTION 5(VL)
2(HL)
4(VR)
3(HR)
6(C)
1(B+)
7(E-)
UP
LEFT DOWN
HAND LEFT
RIGHT
OFF
UP
RIGHT DOWN
HAND LEFT
RIGHT
R L
(E-
)
7 1
(B +)
(VL)
(C)
5 6
4 2 3
(VR)
(HL)
(HR)
Connector Diagram :
