15J. FACIA SWITCHES
Fig. 39 & 40
Function
Functions of different facia switches are given in
following table.
Location
Facia switches are located on the front console.
Fig. 40
Sr.
Description
Legend
Type
Colour of
No.
(Fig. 18)
Sticker
on switch base
1
Dummy
--
--
--
--
2
Switch fuel
Amber
Not latched.
Green
flap
ON only when
(Optional)
Pressed in
3
Switch rear
Green
Latched in
Orange
fog lamp
ON position
4
Switch
Amber
Not latched.
Red
rear window
ON only when
heater
Pressed in
5 Hazard Warning
Red
Latched in
10 pole
Switch
ON position Connector
6
Switch front
Green
Latched in
Orange
fog lamp (if fitted)
ON position
7
Switch rear
Green
Not latched.
Natural
washer
ON only when
Pressed in
8
Switch rear
Green
Latched in
Black
wiper
ON position
Colour of
illumination for
ON state
Fig. 39
IF FITTED
